DESCRIPTION
Valve Cylinder Assembly For Ingersoll Rand Type 30 Model 71T2
PFC - Parts for Compressor is a global supplier of OEM Quality New Aftermarket Replacement Air Compressor Spare Parts for - Valve Cylinder Assembly For Ingersoll Rand Type 30 Model 71T2 from India.
Valve Cylinder Assembly
| Sr.No | Ref. Part Number | Alternate Part Number | Description | Qty |
| 1-9 | 30291801 | W75290T30 | Valve cylinder relief complete | 1 |
| 1-10 | 30209258 | W21461 | – Body relief valve | 1 |
| 1-11 | 30283519 | W21462 | – Bare relief valve | 1 |
| 1-12 | 30279293 | W21848 | – Cap relief valve | 1 |
| 1-13 | 32018731 | X1091PP397 | – Spring relief valve | 1 |
| 1-14 | 37131471 | W75265T3 | Tube assembly with nuts | 1 |
| 1-15 | 95040135 | 75A10B11 | Elbow Tube | 1 |
| 1-16 | 95202800 | 7A16X184 | Nameplate | – |
| 1-17 | 30841456 | W34427 | Stud Drive | 4 |
| 1-18 | 95082491 | 71A10B9 | Connector Tube | 1 |
| 1-19 | 37131463 | W75265T2 | Tube assembly with nuts | 1 |
| 1-20 | 95007522 | 79A10B3 | Tee Tube | 1 |
| 1-21 | 37131455 | W75265T1 | Tube assembly with nuts | 1 |
| 1-22 | 95031852 | 75A10B8 | Elbow Tube | 1 |
| 1-23 | 37101300 | W75301T32 | Head Air complete for automatic start | 1 |
| and stop operation see figure C for | ||||
| valve assembly | ||||
| 1-24 | 37129442 | H36216 | – Head air top half | 1 |
| 1-23 | 37101318 | W75301T33 | Head air complete for (optional) constant | 1 |
| speed or dual control operation | ||||
| 1-24 | 37129467 | H36216P1 | – Head air bottom half | 1 |
| 1-25 | 37007754 | W99832 | – – Gasket between halves | 1 |
| 1-26 | 37129541 | W99843 | – Head air bottom half | 1 |
| 1-27 | 37114030 | W99755 | – – Dowel | 1 |
| 1-28 | 30294508 | W21483 | – – Gasket air head to cylinder | 1 |
| 1-29 | 95043790 | 35A2C227 | Screw cap 1/2 X 3 | 4 |
| 1-30 | 30293015 | W75297T20 | Unloader contant speed complete | 1 |
| (optional) | ||||
| 1-31 | 30209167 | W75297T20B | – Body unloader complete | 1 |
| 1-32 | 30294680 | W21486 | – – Gasket body | 1 |
| 1-33 | 32016578 | R71597 | – Plate unloader | 1 |
| 1-34 | 32012395 | W136434 | – Spring | 2 |
| 1-35 | 30211460 | W75297T20C | – Cover unloader complete | 1 |
| 1-36 | 30294656 | W21487 | – – Gasket Cover | 1 |
| 1-37 | 30284749 | W21467 | – Piston unloader complete | 1 |
| 1-38 | 95022000 | 20A11EM141 | – – O Ring | 1 |
| 1-39 | 32018723 | X1091PP568 | – Spring | 1 |
| 1-40 | 95102042 | 35A2C123 | – Screw cap 3/8 - 16 X 3 1/2 | 4 |
| 1-41 | 30345227 | X1016T34 | – Washer plain 3/8 | 4 |
| stop operation see figure D for valve assy | ||||
| 1-43 | 37130531 | F25229 | – Head air top half | 1 |
| 1-42 | 37101334 | W75301T63 | Head aircomplete for (optional) constant | 1 |
| speed or dual control operation | ||||
| 1-43 | 37130572 | F25229P1 | – Head air top half | 1 |
| 1-44 | 37047156 | R53493 | – – Gasket between halves | 1 |
| 1-45 | 37130549 | W99844 | – Head air bottom half complete | 1 |
| 1-46 | 37114030 | W99755 | – – Dowel | 1 |
| 1-47 | 30294326 | W21948 | – – Gasket air head to cylinder | 1 |
| 1-48 | 95043790 | 35A2C227 | Screw cap 1/2 X 3 | 4 |
| 1-49 | 30292007 | W75297T40 | Unloader constant speed complete | 1 |
| (Optional) | ||||
| 1-50 | 31517709 | W75297T40B | – Body unloader complete | 1 |
| 1-51 | 30294698 | W21485 | – – Gasket body | 1 |
| 1-52 | 32016537 | R71568 | – Plate unloader complete | 1 |
| 1-53 | 32012395 | W136434 | – Spring | 3 |
| 1-54 | 30211460 | W75297T20C | – Cover unloader complete | 1 |
| 1-55 | 30294656 | W21487 | – – Gasket cover | 1 |
| 1-56 | 30284749 | W21467 | – Piston Unloader complete | 1 |
| 1-57 | 95022000 | 20A11EM141 | – – O Ring | 1 |
| 1-58 | 32018723 | X1091PP568 | – Spring | 1 |
| 1-59 | 95102042 | 35A2C123 | – Screw cap 3/8 - 16 X 3 1/2 | 4 |
| 1-60 | 30345227 | X1016T34 | – Washer plain 3/8 | 4 |
