Air Motor Replacement

Vikay is a global supplier of new aftermarket replacement parts - Air Motor for Atlas Copco Wagon Drill Bvb-25 from India.

Product

Air Motor

No.	Description	Modified		Ref. Part No.
-	Piston Motor Complete - 11 Teeth (4450077684)			8973161014
-	Piston Motor Complete - 17 Teeth (4450054188)			8973161006
-	Piston Motor Complete - 9 Teeth			4450077680
1	- Crankcase Feed Rotation & Traction	*
2	- Main Valve Liner			4450071200
3	- Screw (Modified)	0211132400	*	M100003
4	- Double Piston			4350222200
5	- Gasket			4450054400
6	- Cylinder			4450054300
7	- Screw (Modified)	0211132400	*	M100003
9	- Gasket			4450054600
10	- Distributor Plate			4450075200
11	- Spring Washer			0333213000
12	- Screw (Modified)	0211136100	*	M100012
13	- Cover			4350222300
15	- Circlip 16 mm			M100015
16	- Needle Bearing (Modified)	5053010800	*	M100016
17	- Crankshaft Rotation - 11 Teeth (Modified)	9718502700	*	M100017
17A	- Crankshaft Feed Motor - 17 Teeth (Modified)	9718502600	*	M100017A
17B	- Crankshaft For Motor BBE 57 - 9 Teeth (Modified)	4350200900	*	M100017B
18	- Key			0337259200
19	- Gasket			4450055000
20	- Ball Bearing			0502321800
21	- Main Valve			4450054700
22	- Circlip (Int.)			0333215700
23	- Circlip (Ext.)			0335113200
24	- O-Ring			0663613700
25	- Seal Ring			0666226100
26	- Seal Ring Retainer			4450055100

Air Motor Atlas Copco Wagon Drill Parts
