10" DTH Hammers - VD10S x 225
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
10" High Pressure DTH Hammer - VD10S x 225
Vikay is a global supplier of 10" High Pressure DTH Hammer Model VD10S x 225 from India.
Technical Details
| Model | VD10S x 225 |
| Outer Diameter | 225mm (8.85") |
| Hammer Length | 1220mm (48") |
| Hammer Weight | 218kg (480 lbs) |
| Coupler Thread Size | 6 5/8" API | Reg Pin |
Air Consumption, cmf
| 150psi | 250psi | ||
| Min | Max | Min | Max |
| 650 | 1080 | 1230 | 1690 |
Air Consumption, m3/min
| 10 bar | 18 bar | ||
| Min | Max | Min | Max |
| 18.5 | 30.6 | 35 | 47.5 |
| Bit Shank |
| SD-10 |
| No Foot Valve Required |
| 10" To And Above |
Since aprovement are made from time to time, the illustration and specifications are subject to change without notice
