DESCRIPTION
Air motor (K-14S) 9013834103 Replacement Parts
Vikay is a global supplier of new aftermarket replacement parts - Air motor (K-14S) 9013834103 for Alimak Pneumatic Raise Climber from India
Product
- Page 1
Air motor (K-14S) 9013834103
| No. | Description | Designation | Ref. Part No. | ||
| 1-40 | Air motor (K14-H) | 9013834102 | |||
| 1-40 | Air motor (K14-V) | 9013834101 | |||
| 1-40 | Air motor (K14-S) | 9013834103 | |||
| 1 | Crank case | 9001030000 | |||
| 2 | Bearing housing | 0213754000 | |||
| 3 | O-ring | 3000136441 | |||
| 4 | |||||
| 5 | Sign | 0415503000 | |||
| 6 | Ball bearing | 3000115207 | |||
| 7 | Shims set | 0413835000 | |||
| 8 | Sealing ring | 3001406203 | |||
| 9 | O-ring | 3000136410 | |||
| 10 | Spacer | 0413836000 | |||
| 11 | Circlip | SgA 35 | 3000132133 | ||
| 12 | Screw | M6S 10x20-8.8-fz | 3000071491 | ||
| 13 | |||||
| 14 | Plug | 0413688000 | |||
| 15 | O-ring | 3000136408 | |||
| 16 | Screw | MC6S 6x16 -8.8-fz | 3000147368 | ||
| 17 | |||||
| 18 | Crank shaft | 9001033000 | |||
| 19 | |||||
| 20 | Crank bearing (Modified) | 0419764000 | |||
| 21 | Tension pin | FRP 4x8 | 3000134250 | ||
| 22 | Counterweight | 313839 | 9001039000 | ||
| 23 | Key | 3000742370 | |||
| 24 | Screw | 9001037000 | |||
| 25 | Piston | 313844 | 9013773000 | ||
| 26 | Piston ring | 0415348000 | |||
| 27 | Cylinder | 0313756000 | |||
| 28 | Gasket | 0413845000 | |||
| 29 | |||||
| 3038 | Compl. slide housing | * | |||
| 30 | O-ring | 3000136426 | |||
| 31 | Circlip | SgH 72 | 3000133153 | ||
| 32 | Slide bush | 0413846000 | |||
| 33 | Slide | * | |||
| 34 | |||||
| 35 | |||||
| 3637 | Slide housing w. bushing | 9018693000 | |||
| 36 | Slide housing | ||||
| 37 | Slide bushing | ||||
| 38 | O-ring | 3000136429 | |||
| 39 | Screw | MC6S 10x20-8.8-fz | 3000147491 | ||
| 40 |
Rotationsriktning **Beteckning * *
Rotating direction Designation Pos./Item Pos./Item Pos./Item
Rotationsrichtung Bezeichnung 33 30 38 1 40
Hger/Right/Rechts K 14-H 9005808000 9016539102 9013834102
Vänster/Left/Links K 14-V 9005807000 9016539101 9013834101
Bda/Both/Beide K 14-S 9005809000 9016539103 9013834103
