Compl. Control Valve - Old Type Alimak Raise Climber Parts
This product is not available in the selected currency.
In Stock
Backordered
Out of Stock
Description
Complete Control Valve (Old Type) Replacement Parts
Vikay is a global supplier of new aftermarket replacement parts - Complete Control Valve (Old Type) - for Alimak Pneumatic Raise Climber from India.
Product
- Page 1
Complete Control Valve (Old Type) Replacement Parts
| No. | Description | Designation | Ref. Part No. |
| 1 | Valve housing | 113638 | |
| 2 | O-ring | 134.5 X 3 | |
| 3 | Cover | 313640 | |
| 4 | Filter pad | 413675 | |
| 5 | Screw | MCS 5 X 30 | |
| 6 | Nut | M6M 5 | |
| 7 | Filter washer | 413676 | |
| 8 | O-ring | 44.2 X 3 | |
| 9 | |||
| 10 | |||
| 11 | Slide bushing compl part of 115344 | 413679 | |
| 11 | Slide bushing compl.part of 176216 | 476401 | |
| 12 | Clamping pin | Ǿ 6 X 24 | |
| 13 | Distance tube | 413680 | |
| 14 | Washer | 413681 | |
| 15 | Outer spring | 413682 | |
| 16 | Inner spring | 413683 | |
| 17 | Distance tube | 413684 | |
| 18 | Spring housing | 313639 | |
| 19 | Washer | 413685 | |
| 20 | Lock ring | SgA-12 | |
| 21 | Pull rod | 413686 | |
| 22 | Plug R 1/2" | 413687 | |
| 23 | O-ring | 17.3 x 2.4 | |
| 24 | Screw | U6S 5/16" UNC X 22 | |
| 25 | Washer | BRBÂ 8.4 X 16 | |
| 26 | Screw | U6S 3/8" UNC X 32 | |
| 27 | Washer | BRBÂ 10 X 18 | |
| 28 | Plug R 1" | 413688 | |
| 29 | O-ring | 29.2 X 3 | |
| 30 | Clamping pin | 10 X 45 | |
| 31 | Bracket for lever | 413689 | |
| 32 | Hand lever | 313690 | |
| 33 | Bakelite ball | Ǿ 40 | |
| 34 | Filter washer | 413676 | |
| 35 | Filter pad | 413691 | |
| 36 | Nut | M6M 5 | |
| 37 | Screw | MCS 5 X 60 | |
| 38 | Cone | 413693 | |
| 39 | O-ring | 29.2 X 3 | |
| 40 | O-ring | 13.3 X 2.4 | |
| 41 | O-ring | 134.5 X 3 | |
| 42 | Plug | 413694 | |
| 43 | Suck hose with filter | 413695 | |
| 44 | Ventilation tube | 413696 | |
| 45 | Oil tube | 413697 | |
| 46 | Screw | U6S 3/8" UNC X 82 | |
| 47 | Washer | BRB 10 X 18 | |
| 48 | Oil container | 313641 | |
| 49 | Drop housing | 413698 | |
| 50 | Observation glass | 413699 | |
| 51 | Drop screw | 413700 | |
| 52 | Felt washer | 413701 | |
| 53 | Thrust washer | 413702 | |
| 54 | 0-ring | 13.3 X 2.4 | |
| 55 | Adjusting screw | 413703 | |
| 56 | Nut | KM 4 | |
| 57 | 0-ring | 11.3 x 2.4 | |
| 58 | 0-ring | 29.2 x 3 | |
| 59 | Plug | 413704 | |
| 60 | Throttle washer (only for 176216) | 476474 |
Details
- type: product
- SKU: Alimak10
