DESCRIPTION
CP 0020 Chicago Pneumatic Sump Pump
| Particulars | CP 0020 | |
| Power | kW | 2,9 |
| Weight | kg | 30,5 |
| Min opening needed | mm | 230x240 |
| Min water depth | mm | 22 |
| Max suction lift | m | - |
| Max head | m | 27,4 |
| Air consumption | l/s | 51 |
| Air inlet | inch | 3/4" NPT |
| Air outlet | inch | 1 1/4" NPT |
| Discharge inlet | inch | - |
| Discharge outlet | inch | 2½" BSP |
| Max solid content | - | |
| Sound power level guaranteed (2000/14/EC) 1) | dB(A) | 122 |
| Sound pressure level (ISO 11203) 1) | dB(A) | 109 |
| Sound power uncertainty value K | dB(A) | 2,5 |
| Recommended air supply hose size | mm | 25 |
| Part number (at 6 bar) | T022185 | |
| Stock Code No. | Z0010466 |
