DESCRIPTION
Assembly Cylinder 16 & 10 x 7 IHE NL Compressor Replacement Parts
PFC - Parts for Compressor is a global supplier of OEM Quality New Aftermarket Replacement Air Compressor Spare Parts for Assembly Cylinder 16 & 10 x 7 IHE NL Compressor from India
Assembly Cylinder 16 & 10 x 7 IHE NL
| SR. NO. | DESCRIPTION | PART NUMBER | QTY |
| FIG2A/2C | – Assembly Cylinder 10 x 7 NL | 70263026 | 1 |
| 2A2D | – – Cylinder 10 IHE | 70412051 | 1 |
| – | – – Cover Water Cylinder | 39535661 | 2 |
| – | – – Gasket Water Cover PHE-7 | 39535638 | 2 |
| – | – – Screw Cap Hex 1/2 in x 1 in | 95104147 | 12 |
| – | – – Plug Pipe Sq. Hd. 1/2 NPT | 95033619 | 3 |
| – | – – Reducer Bushing 1/2 NPT X 1/4 NPT | 95002044 | 1 |
| – | – – Gasket Cylinder 10 | 70412689 | 2 |
| – | – – Nameplate | 40036519 | 1 |
| – | – – Screw Machine 0.114" x 0.25" | 39175070 | 4 |
| – | – – Plug Pipe Sq. Hd 1/4 NPT | 95033593 | 2 |
| 2A21 | – – Stud 1 x 4 | 95594487 | 8 |
| 2A22 | – – Nut Hex 1 in | 95077749 | 8 |
| – | – – Plug Sp Lubricator Hole | 30510069 | 1 |
| – | – – Pin Roll 3/8 x 1 | 95098687 | 2 |
| 2C1 | – – Footpiece 5 in x 150 Hydrotested | 94432697 | 1 |
| 2C2 | – – Gasket Flange 5 in x 150# | 94475480 | 1 |
| 2C3 | – – Bolt Hex Head 3/4 in x 2 in | 95035440 | 8 |
| 2C5 | – – Plate Sole IHE | 30194989 | 1 |
| 2C6 | – – Screw Cap Hex Head 3/4 x 1-3/4 | 95104642 | 4 |
| 2C4 | – – Spacer Foot Piece | 30199087 | 1 |
| – | – – Valve Drain 1/4 NPT | 94426210 | 1 |
| – | – – Flange Closer 5 in x 150# | 97100747 | 1 |
| – | – – Plug Sp Lubricator Hole | 30510069 | 1 |
| 2A23 | – – Stud 1 x 4 | 95594487 | 8 |
| 2A24 | – – Nut Hex 1 in | 95077749 | 8 |
