Vikay Pneumatic Drifter VK-12FZ

Vikay is a Global Supplier of Pneumatic Drifter VK-12FZ from India.

Vikay top Hammer Heavy Duty Rock Drill / Pneumatic Drifter Model VK-12FZ

VK-12FZ Drifter is used for long hole drilling, bench drilling and drifting hole sizes FZ 51-89mm (2"-31/2")

The Drifter is specially designed for underground mining work.

The VK-12FZ Drifter is Rifle-Bar rotated heavy-duty Rock Drill mounted on Rig best suitable for drifting and tunnelling. The Drifter is specially designed to use in underground Mining and Tunnelling for Ring Drilling and Face Drilling, It also has a feature of reversible Rotation, which can also be disengaged so that only impact mechanism works. One of the key features of this drifter is that it can be converted from water flushing to air blowing. The parts for Drifter VK-12FZ are interchangeable with Atlas Copco BBC 120FZ.

Features -

• It is operated from Control Unit
• It has a feature of Reversible Rotation, which can also be disengaged so that only impact mechanism works
• It has a Rifle-bar actuated rotation motor with eight pawls (four for each direction) that engage or disengage
• It can be easily be  converted from water flushing to air blowing
• Hoses can be placed on either side to protect from unintentional abuse
• The machine is specially designed for underground mining work.

Technical Details

Flushing is possible as air blowing or water flushing, all drill functions are operated from a control unit

Since approvement are made from time to time, the illustration and specifications are subject to change without notice.
