Feed Beam With Motor MBMS 46
Regular price
₹0.00
Feed Beam With Motor MBMS 46
Regular price
₹0.00
DESCRIPTION
Feed Beam With Motor MBMS 46 for Atlas Copco Simba Junior Parts
Vikay Mining Equipments is a global supplier of new aftermarket replacement parts for Feed Beam With Motor MBMS 46 of Atlas Copco Simba Junior from India
Product
- Page 1
Feed Beam With Motor
| No. | Description | Modified | Ref. Part No. | ||
| Feed Beam With Motor | MBMS46 | ||||
| Beam Complete | 3142016080 | * | M900080 | ||
| 1 | - Beam With Screw - Steel Casting | 3142016000 | * | M9001 | |
| 2 | - Screw | 0147140400 | |||
| 3 | - Nut | 3142016300 | |||
| 4 | - Guide Rail | 3142023100 | |||
| 5 | - Lock Washer | 0333313700 | |||
| Feed Screw Complete | 3142016580 | * | M900680 | ||
| 6 | - Feed Screw Complete With Castle Nut | 3142016500 | |||
| 8 | - Spiral Pin | 3142046300 | |||
| 18 | - Gear Wheel | 3142017800 | * | M9016 | |
| 19 | - Nut | 3142017900 | * | M9017 | |
| A | - Bearing Casing Bottom Complete - Motor Side | * | M9900 | ||
| 7 | --Split Pin | 3142046200 | * | M9007 | |
| 9 | -- Spacer Sleeve | 3142016800 | * | M9008 | |
| 10 | --Seal Ring | 3142016900 | |||
| 11 | -- Cover | 3142077700 | * | M9009 | |
| 12 | -- Oil Seal | 0666226300 | * | M9010 | |
| 13 | --Ball Bearing | 0502110600 | * | M9011 | |
| 14 | -- Spacer Ring (8 mm) | 3142017500 | * | M9012 | |
| 15 | -- Thrust Bearing | 0511010600 | * | M9013 | |
| 16 | -- Spacer Sleeve | 3142017600 | * | M9014 | |
| 17 | -- Bushing | 3142076000 | * | M9015 | |
| 72 | -- Spacer Ring (9 mm) | 3142017500 | * | M9051 | |
| Motor Housing Comp | 3142018082 | ||||
| 20 | - Motor Housing with Adapter | - | |||
| 21 | - Adapter | 3142028400 | |||
| 22 | - Gasket | 0653116300 | |||
| 23 | - Guide Pin | 3142018100 | |||
| 24 | - Liner | 3142018200 | |||
| 25 | - Main Valve | 3142018300 | |||
| 26 | - Gear Wheel | 3142018400 | |||
| 27 | - Ball Bearing | 0502110400 | |||
| 28 | - Ball Bearing | 0502210400 | |||
| 29 | -Cover | 3142018500 | |||
| 30 | - Screw | 0147132300 | |||
| 31 | - Spring Washer | 0333212500 | |||
| 32 | - Eccentric Shaft | 3142018600 | |||
| 33 | - Needle Cage - Set | 3142023200 | |||
| 34 | - Bearing Race | 3142018700 | |||
| 35 | - Stop Washer | 3142018800 | |||
| 36 | - Circlip | 0335113200 | |||
| 37 | -Ball Bearing | 0502110600 | * | M9011 | |
| 38 | - Bearing Cover | 3142018900 | |||
| 39 | - Ball Bearing | 0502210400 | |||
| 40 | - O Ring | 0663613600 | |||
| 41 | - Circlip | 0335215600 | |||
| 42 | - Banjo Connection | 3175029500 | |||
| 43 | - Pressure Screw | 0627512600 | |||
| 44 | - Gasket | 0653116300 | |||
| 45 | - Piston | 3142044100 | |||
| 46 | - Piston Ring | 0680120200 | |||
| 47 | - O Ring | 0663313400 | |||
| 48 | - Cylinder Head | 3142019300 | |||
| 49 | - Circlip | 0335214400 | |||
| 50 | Stud | 3142019400 | |||
| 51 | Dome Nut | 3121029200 | |||
| 52 | Motor Holder Right | 3142019500 | |||
| 53 | Motor Holder Left | 3142019600 | |||
| 54 | Screw | 0147149400 | |||
| 55 | Nut | 0291116400 | |||
| 56 | Spring Washer | 0333214300 | * | M9025 | |
| 57 | Screw | 3142021700 | |||
| 58 | Nut | 3142077500 | |||
| 59 | Feed Nut | 3161067900 | |||
| 60 | Buffer | 3142019800 | |||
| B | Bearing Casing Top Complete - MBSP-10 Side | 3142031080 | * | M9030 | |
| 62 | - Washer | 3142031200 | * | M9031 | |
| 63 | - Sleeve | 3142031500 | * | M9032 | |
| 64 | - Bearing Casing | 3142031600 | * | M9033 | |
| 65 | - Screw | 3142031300 | * | M9034 | |
| 66 | - O Ring | 3142034300 | * | M9035 | |
| 67 | - Bearing Bracket | 3142031000 | * | M9036 | |
| 68 | - Bushing PB | 3142031400 | * | M9037 | |
| 69 | - Ring Seal | 0666229500 | * | M9038 | |
| 70 | -O Ring | 0663212700 | * | M9039 | |
| 71 | - Lubricating Nipple | 0544216200 | * | M9040 |
