Intercooler Assembly IR 15T2 Compressor Parts

Description

Intercooler Assembly For Ingersoll Rand Type 30 - Model 15T2

PFC - Parts for Compressor is a global supplier of OEM Quality New Aftermarket Replacement Air Compressor Spare Parts for - Intercooler Assembly For Ingersoll Rand Type 30 - Model 15T2 from India.

Product

Page 1

1. Intercooler Assembly

Sr.No	Ref. Part Number	Description
10-1	37131109	Assembly, Tube - Intercooler/3rd Stage
10-2	95031761	Elbow, Tube - 3/4 X 3/4
10-3	95083275	Connector, Tube 3/4 X 3/4
10-4	97048094	Valve, Safety - 60 PSIG
10-5	72062102	Valve, Safety - 260 PSIG
10-6	95736898	Gauge, Pressure -100 PSIG (32127896)
10-7	95736922	Gauge, Pressure -300 PSIG(32013898)
10-8	30282396	Damper Assembly - Pulsation
10-9	95110441	Elbow, Tube - 1/4
10-10	95006524	Tee, Pipe -1/4
10-11	95426714	Nipple, Close - 1/4 X 7/8
10-12	95053070	Capscrew - Hex 1/4-20 X 1/2
10-13	30218283	Shroud, Inter - Cooler, Bottom
10-14	30218275	Shroud, Inter - Cooler, Top
10-15	95053070	Capscrew-Hex 1/4-20 X 1/2
10-16	95094298	Washer, Flat - 1/4
10-17	95043196	Lockwasher, Spring - 1/4
10-18	30209829	Brace, Inter - Cooler Shroud
10-19	32024697	Tube Assembly, Finned -36"
10-20	32025678	Tube Assembly, Finned -38 - 3/4"
10-21	32025686	Tube Assembly, Finned -41 -1/2"
10-22	95083143	Connector, Male - 3/8 X 1/4"
10-23	95033338	Plug, Square Countersunk -1-1/4"
10-24	95033338	Plug, Square Countersunk -1
10-25	95043808	Capscrew-Hex 5/8-11 X 2-1/4
10-26	95002168	Capscrew-Hex 5/8-11 X 2-1/2
10-27	30345185	Washer, Flat - 5/8
10-28	37129038	Manifold, Intercooler
10-29	37129046	Manifold, Intercooler
10-30	30294870	Gasket, Manifold
10-31	30221121	Connection, Manifold
